IEC60061-3: 7006-29-3 American Standard Gauge for Testing Contact-Making of Lamps Fitted With Caps E26/24

China IEC60061-3: 7006-29-3 American Standard Gauge for Testing Contact-Making of Lamps Fitted With Caps E26/24 supplier

Large Image :  IEC60061-3: 7006-29-3 American Standard Gauge for Testing Contact-Making of Lamps Fitted With Caps E26/24

Product Details:

Place of Origin: Made in China
Brand Name: JLX
Certification: ISO 17025 CNAS & ILAC Test Report
Model Number: 7006-29-3

Payment & Shipping Terms:

Minimum Order Quantity: 1
Packaging Details: Export standard packing
Delivery Time: 5 working days
Payment Terms: T/T, Western Union
Supply Ability: 200 per month
Contact Now
Detailed Product Description
Standard: IEC60061

Gauge for testing contact-making of lamps fitted with caps E26/24 7006-29-3



Purpose:
To check lamp dimensions for contact-making in E26, E26/50x39, E26/51x39 or E26d lampholders.



Testing:
The shape of the lamp with regard to the fit in the lampholder is assumed to be correct, if the lamp can be pushed into the gauge until plane W reaches plane V or projects beyond it. For E26/24 capped lamps, when surfaces V and W are coincident, the top of the cap including any solder or conductive material, shall not extend above surface X.



IEC60061-3: 7006-29-3 American Standard Gauge for Testing Contact-Making of Lamps Fitted With Caps E26/24
